Creality Sermoon P1 3D Scanner

The Creality Sermoon P1 is an advanced and professional 3D scanner that combines accuracy of up to 0.02 mm with a very fast scan. Thanks to its hybrid system of 22 + 7 + 1 blue laser lines and dual NIR structured light, it accurately maps both large elements and fine details or deep holes — it works well with objects from 5 mm³ to 4000 mm³. The integrated Qualcomm octa-core processor, the Adreno 740 GPU, 24 GB of RAM and 256 GB of ROM allow you to scan and process models even without a computer. You can also choose from 3 operating modes. It is a mobile and comprehensive tool for professional engineering, quality control and digitization of objects — ready for use in the office, in production and in the field.

Hybrid scanning system — higher accuracy, better results

The Sermoon P1 uses a hybrid light source: 22 crossed laser lines for a quick acquisition of the geometry of large elements, 7 parallel lines for precise mapping of details and 1 line for scanning deep holes. This is complemented by the dual NIR structured light, which allows for the rapid scanning of larger objects and human figures without the use of markers. This configuration allows the operating mode to be adapted to the material, size and complexity of the scanned element, ensuring complete coverage of both large surfaces and complex structures.

Three operating modes — freedom in all conditions

The Sermoon P1 offers three operating modes. Standalone mode allows scanning without connecting a computer, at speeds of up to 60 FPS. Wireless PC uses Wi-Fi for fast and stable data transmission, allowing you to work without cables. In Wired PC mode, the device achieves maximum performance (up to 100 FPS) — this is the solution for the most demanding industrial projects.

Accuracy you can count on

Accuracy of up to 0.02 mm (laser) and 0.075 mm (infrared), as well as volumetric accuracy of 0.02 mm + 0.06 mm/m, guarantee repeatable and reliable results in professional applications such as reverse engineering and quality control. The 3D resolution in the range of 0.05—2 mm (laser) and 0.1—2 mm (NIR) allows both fine details and larger solids to be mapped with high data quality. This level of accuracy allows for uncompromising analysis, design, and inspection.

Scan deep holes and hard to reach spaces

The single-line laser mode has been optimized for use in deep holes, tight crevices, and indentations. The device supports hole scanning with a depth-to-diameter ratio of up to 5:1, allowing 3D data to be acquired from places inaccessible to many standard scanners. In practice, this means a more complete model of mechanical components, more accurate inspections, and better support for design and analysis processes.

Real-time performance — up to 100 FPS and millions of dots per second

Laser scanning reaches speeds of up to 60 FPS in Standalone mode and up to 100 FPS in PC mode. The infrared mode offers up to 18 FPS (Standalone) and 30 FPS (PC). In addition, in wired mode, the device acquires up to 1,740,000 points/s (22 blue laser lines) or 6,881,000 points/s (NIR). Such a high data collection speed translates into smooth real-time reconstruction, stable tracking and shorter project completion times — even with complex and demanding objects.

Independent operation without a computer — powerful components on board

The Sermoon P1 integrates a 3.36 GHz octa-core Qualcomm processor, an Adreno 740 GPU and an FPGA chip, which allow fast scanning and data processing without the need to connect to a computer. In addition, 24 GB of LPDDR5X RAM offers high bandwidth and low latency, while 256 GB of UFS 4.0 storage speeds up file saving and transfer. You also have built-in software that supports calibration, scanning, point cloud merging, mesh editing, and merging multiple scans, allowing you to complete model processing directly on the device.

Innovative 4-lens system — precision and wide field of view

The scanner is equipped with a 4-lens system: it offers high-resolution objectives shared with a blue laser and wide-field of view objectives. This solution reduces the need for markers, improves tracking stability, and speeds up working with large objects, including the scanning of human figures.

Mobility, ergonomics and uninterrupted power

The scanner weighs 830g and is equipped with a 6-inch Full HD touchscreen with a 160° viewing angle, which provides a clear and bright image even outdoors. Two removable batteries with independent USB-C ports (3300 mAh each) allow for extended work in the field, and the 65W PD 3.0 fast charge allows you to reach 80% in about 50 minutes. An intelligent energy saving system, which automatically activates sleep mode, also guarantees efficient and environmentally friendly operation. In addition, the integrated Wi-Fi 7 module offers speeds up to 4.8 times faster than Wi-Fi 6 and, combined with lossless compression algorithms, provides a fast, secure and stable connection. Also noteworthy is the practical handle and the included case, which allows the scanner and its accessories to be transported safely.

Large scan range

The device allows you to scan both small objects of 5 × 5 × 5 mm and very large objects up to 4000 × 4000 × 4000 mm. This makes it ideal for a variety of scenarios: you can easily digitize coins, figurines, sculptures, mechanical parts, and even people and vehicles. The maximum field of view in laser mode is 380 × 365 mm at 550 mm, and in infrared mode it is a whopping 1245 × 754 mm at 1000 mm, allowing an entire human figure to be scanned in about a minute. The larger FOV also reduces the need for markers and improves tracking stability when working with large objects.

Works well on difficult surfaces and outdoors

The Sermoon P1 manages black and metallic surfaces without the need for mattifying sprays. In addition, the system works effectively under lighting conditions of up to 100,000 lux (single line mode and 22 crossed lines), up to 50,000 lux (7 lines) or up to 30,000 lux in NIR mode. This allows the device to be successfully used in a variety of environmental conditions, both in production and in the field.

Realistic textures and global shutter

The integrated RGB camera with global shutter and 12 LEDs (blue and white) allow accurate scanning of the textures and colors of the objects. The color mapping is managed by a Qualcomm ISP chip with advanced algorithms, which results in an accurate and saturated reproduction of shades and surface details. This makes the Sermoon P1 ideal for archiving artwork, working in the creative sector, or creating realistic models for viewing.

Stable scanning thanks to AI

The scanner uses an AI-based temperature compensation algorithm, which, combined with an optimized thermal design, ensures stable and reliable operation regardless of conditions. The system minimizes the impact of temperature on measurements, maintaining stability and repeatability of results even during long scanning sessions. This is especially useful in professional applications such as reverse engineering or quality control, where data consistency is of paramount importance.

Software tailored to your needs

The scanner works with the CrealityScan software available for Windows and macOS. In addition, scan data can be seamlessly exported and imported into popular engineering, inspection, and design programs such as QuickSurface, Geomagic Design X, Siemens NX, CATIA, Creo, SolidWorks, Maya, 3DMax, Rhino, Cinema4D, ZBrush, Meshmixer, Mudbox, Meshlab, Unreal Engine, Fusion 360, and Blender. Wide compatibility makes the Sermoon P1 a simple integration into existing workflows in the automotive, manufacturing, reverse engineering, quality inspection and artistic digitization sectors.

Included in the set

• Creality Sermoon P1 x1 3D Scanner
• High precision glass calibration plate x1
• USB-C 3.0 cable (2 m) x1
• Power adapter with adapters x1
• Reflective markers D6 mm x10
• Reflective markers D3 mm x10
• Replacement battery x1
• Cleaning cloth x1
• String x1
• Quick Start Guide, Declaration of Conformity and Warranty Card x1
• Carry case x1
