Revopoint MetroY Ultra 3D Scanner - Standard Edition
Best online price for Revopoint MetroY Ultra 3D Scanner - Standard Edition.
Brand: Revopoint -
Code: INN_METROY-ULTRA-SE - Ean: 6975577881977
€ 2481.50
€ 2977.80
You save € 496.30
(−17%)
Available in stock
Revopoint MetroY Ultra 3D Scanner (Standard Edition) for highly accurate surveys: single accuracy of up to 0.015 mm and volumetric accuracy for consistent measurements. Up to 90 fps and up to 3,000,000 dots/s for fast scans. Wi‑Fi 6 with real-time transfer, 5 modes (high speed, details, deep holes, structured light) and outdoor work with lighting up to 100,000 lux. Ideal for quality control and 50—1,000 mm parts.
Description
Revopoint MetroY Ultra 3D Scanner - Standard Edition Description
Revopoint MetroY Ultra 3D Scanner - Standard Edition
The Revopoint MetroY Ultra 3D Scanner is an advanced tool that combines blue light technology, multiline laser and structured light to achieve an accuracy of 0.015 mm per single scan. It operates at up to 90 frames per second, capturing up to 3,000,000 dots per second for fast and extremely accurate mapping. Thanks to Wi-Fi 6 connectivity, real-time data transfer is possible, while the Revo Metro software supports a complete workflow: from scanning to analysis and measurement. Ideal for precision quality control and machining on small and medium-sized parts.
Industrial-grade measurement accuracy
The Metroy Ultra not only offers single-scan accuracy of up to 0.015 mm, but also high volumetric accuracy, ensuring consistency in measurements even on large objects. This high precision makes it ideal for applications that require strict quality control and accurate dimensional analysis, reducing production errors and increasing process repeatability.
Fast and flexible scanning in all conditions
Designed for maximum performance, the MetroY Ultra offers scans of up to 90 FPS and an exceptional laser speed of 3,000,000 dots per second. It also handles difficult lighting conditions, operating with luminous intensities of up to 100,000 lux. The support for objects of various sizes, from about 50 mm to 1,000 mm, makes it a versatile tool for both small components and larger industrial parts.
5 scan modes for every need
The device offers five blue light scanning modes to adapt to each specific application. The High Speed mode with 34 crossed lines allows quick data collection, while the Details mode with 15 parallel lines guarantees high surface resolution. The single-line mode is ideal for scanning deep holes, and the structured light is effective for mapping larger surfaces. In addition, the automatic turntable mode allows smaller objects to be scanned unattended, greatly speeding up the workflow.
Professional software and complete data control
The scanner is compatible with Revo Metro and Revo Measure software, which offer advanced analysis and measurement functions. The measurement algorithms are certified by the German Metrology Institute PTB, confirming compliance with international standards. Users benefit from an intuitive interface, texture visualization and the ability to export measurement reports, ensuring a smooth transition from scanning to final analytical data.
Wireless operation
With Wi-Fi 6 support and wireless scanning capabilities, the MetroY Ultra offers complete freedom from cables. The screen mirroring function allows you to simultaneously view the scan progress on various devices, such as monitors or smartphones. This significantly improves process control and allows you to work comfortably in different environments, both in the office and in production.
Wide application in industry and engineering
The MetroY Ultra is used in various sectors: from reverse engineering to rapid prototyping, from quality control to the preparation of models for 3D printing. Thanks to its high accuracy and versatility, it helps to reduce design times and increase precision, optimizing design and production processes.
Included in the package
- Scanner
- Tripod
- USB Type-C to Type-C cable
- Power supply
- Model sample
- 6 mm markers (500 pcs)
- Biaxial swivel platform
- Carry case
- Calibration plate
- Mobile Kit (4th Generation)
| Producer | Revopoint |
|---|---|
| Model | Metro Y Ultra |
| Single scan accuracy | up to 0.01 mm |
| Single scan accuracy | up to 0.015 mm |
| Volumetric accuracy | 0.015 mm + 0.04 mm × L (m), where L is the length of the object |
| Distance between points | up to 0.05 mm |
| Working distance | 200—400 mm |
| Single scan area at minimum distance | 152 × 138 mm to 200 mm |
| Single scan area at maximum distance | 332 × 276 mm to 400 mm |
| Minimum scan volume | 10 × 10 × 10 mm |
| Maximum scan volume | 2 × 2 × 2 m |
| Scan speed | NVIDIA GPU: up to 90 fps CPU: up to 60 fps |
| Point capture speed | Multiline scan: 3,000,000 dots/s Structured light scan: 7,000,000 dots/s |
| RGB camera resolution | 2 MP |
| Processor | Quad-core ARM, 2.0 GHz |
| External scan | Yes (multiline laser mode allows operation in light conditions up to 100,000 lux) |
| 3D light source | 34 blue crossed lines 15 parallel blue lines 1 blue line for deep holes 62-line full-field blue structured light |
| lighting | 12 blue LEDs |
| Scanner weight | 450 g |
| Dimensions (W × D × H) | 211 × 94 × 47 mm |
